Energy Bollard TONDO 325

  • Made of stainless steel (1.4301)
  • Powder coating DB703
  • Access to internal distribution lockable
  • Operation with closed door
  • Version with electricity, data technology, water and waste water

Versions

further versions on request

Quantity Output MCB RCD Input Item-No.
1 CEE 32A 5pol./400V 1 x LS 32A 3p.C FI 63A/0,03A/4p. 1 x M40 from below 73011480
1 CEE 16A 5pol./400V 1 x LS 16A 3p.C
4 Power outlet230V 2 x LS 16A 1p.B
1 CEE 32A 5pol./400V 1 x LS 32A 3p.C FI 63A/0,03A/4p. 1 x M40 from below 73011390
1 CEE 16A 5pol./400V 1 x LS 16A 3p.C
3 Power outlet 230V 3 x LS 16A 1p.B
2 CEE 32A 5pol./400V 2 x LS 32A 3p.C FI 63A/0,03A/4p. 1 x M40 from below 73020390
3 Power outlet 230V 3 x LS 16A 1p.C
2 CEE 16A 5pol./400V 2 x LS 16A 3p.C FI 63A/0,03A/4p. 1 x M40 from below 73002390
3 Power outlet 230V 3 x LS 16A 1p.C

Subject to change and errors excepted

Technical specifications

  • Dimensions: diameter: 325mm, height: app.850mm
  • Operation with closed door
  • plastic distributor
  • Protection class IP 54
  • Stainless steel bollard with powder coating DB 703
  • Feed-in from below
  • wired ready for connection
