Flood-proof Underfloor Distributor

PLAZA PROtector 900TT

  • The cable is automatically protected in the cable outlet area. Highest personnel and system protection
  • global M Technic quality with built-in cable outlet protection system “PROtector”
  • use in places at risk of flooding
  • no damage during operation
  • the underfloor distributor is invisible
  • the cable outlet cover protects always
  • energy-saving winter mode
  • no maintenance-prone spindle drives
  • long service life even in harsh environments

Function

The PLAZA PROtector 900TT underfloor distributor is equipped with a diving bell for operations in areas that require protection against flooding or flooding by heavy rainwater. As a result, no water can penetrate into the interior of the manifold even at a high water level above the underfloor distributor. Due to the solid rubber distributors used with a wall thickness of up to 15 mm, the underfill distributors are additionally protected against condensation water compared to plastic distributors.

Of course, our flood-safe underfloor distributors are protected by our patented cable protection system “PROtector” at the area of the cable outlet (see following film). This also allows the cable outlet area to be traversed for the first time with the full load capacity of 40t. A safety barrier so that you do not lose the admission for 40t is therefore no longer necessary. If the underfloor distributor is no longer required, the “PROtector” cable protector is folded over and the cable outlet area is invisibly protected by a fillable cable outlet lid.

Application

Therefore it must be carried out for the first time no safety barrier in working condition. The Underfloor Distributor PLAZA PROtector 900TT is also invisible in operation and the idle state by the filled cover and the fillable cable exit cover. The cables and hoses are routed only through a cable outlet to the outside. This also offers even in operating condition a customized appearance and is protected against accidental or intentional damage or unauthorized electricity or water extraction.

M Technic Underfloor Distributor / Floor Pits / Hatch Pits are often used in market places, in the closed area of historic buildings, hangars, industrial buildings, event centers and sports facilities to ensure their high plant availability a reliable supply of power, data, water and compressed air supply.

Technical specifications

  • with folded PROtector for complete cable protection in the cable outlet area
  • Protection class IP 68 (flood-proof) with closed cover, IP 54 with lid open
  • solid rubber distributor, equipping according to customer requirement
  • with fillable cover and fillable cable exit lid
  • built-in lid heating for operation even in case of frost and for the water connection
  • variable thermostat
  • maintenance-free stainless steel gas springs for easy opening
  • Additional versions for data technology, water, sewage and compressed air
  • Installed terminal distributor for the underground cable
  • Construction made of solid stainless steel V2A (1.4301)
  • Abmessungen: ca. 922 mm x 905 mm x 500 mm
  • Weight app. 290 kg
  • load 400 kN (40 t) in accordance with DIN EN 124

Characteristics

  • during operation is the Underfloor Distributor and even the cable outlet area of lorries traversable
  • patented Cable Protection System PROtector
  • Flood – proof IP 68
  • operationally in closed state
  • the cover and the cable exit lid can be filled
  • inevitable protection of the cables in the cable outlet area, either by the Protector or by the cable outlet lid
  • thermostat-controlled heating for the lid
  • automatic opening on gas springs
  • fully A2 stainless steel (1.4301) produced
