Function
The cable bridge X7 is equipped with 5 extremely large channels, 3 of which are even suitable for C-tube types of the fire brigades (Ø 52 mm). It also offers excellent protection even for power lines. The cable bridge X7 has been developed to protect against heavy trucks and is equipped with a non-slip yellow warning cover. This carries a tire load of 6 tons (20 x 20 cm). The lid closes on an integrated patented zipper. No stones, broken pieces or other dangerous objects can be pressed into the cable or hose through the protective cover.
Technical specifications
- Length: approx. 700 mm
- Width: approx. 696 mm
- Height: approx. 87 mm
- Channels: 5
- Width (channels): 6.1 cm, 6.2 cm, 6.0 cm, 6.2 cm, 6.1 cm
- Height (channels): 5.9 cm, 6.5 cm, 6.3 cm, 6.5 cm, 5.9 cm
- Material: PU (polyurethane)
- Flame protection class: B2
- Operating range: -30°C to +60°C
- Load capacity: approx. 6t with an area of 20 x 20 cm
- Resistant to oil, acid and petrol
- Weight: approx. 20,8 Kg
Characteristics
- extremely high load-bearing capacity
- yellow warning colour in the lid
- captive lid
